Carrier 23XRV5568NRAA50-S 500 Ton Water-Cooled Liquid Chiller – 2012, R-134a

Overview

For sale is a Carrier 23XRV Series Water-Cooled Centrifugal Liquid Chiller, model 23XRV5568NRAA50-8, featuring oil-free magnetic bearing technology for ultra-efficient performance. This unit was manufactured in 2012 and is ideal for large commercial or industrial HVAC applications.

Key Specifications

• Model: 23XRV5568NRAA50-S
• Serial Number: 4912027226
• Capacity: 500 Tons
• Refrigerant: R-134a (Factory Charge: 1200 lbs / 580 kg)
• Voltage: 460V / 3 Phase / 60 Hz
• Compressor Type: Oil-free centrifugal
• Design Pressure:
• Cooler: 186 PSIG
• Condenser: 186 PSIG
• Oil: 250 PSIG
• Test Pressure:
• Cooler: 280 PSIG
• Condenser: 280 PSIG
• Oil: 300 PSIG

Electrical Specs

• Locked Rotor Amps: 705 A
• Overload Trip Amps: 366 A
• Max Fuse/Breaker Size: 700 A
• MCA (Min Circuit Ampacity): 444 A
• Motor Nameplate HP: 480V
• Compressor Full Load Amps: 366 A
• Oil Pump: 115V, 1.4A / 500W
• Oil Sump Heater: 115V, 0.9A
• Oil Vaporizer Heater: 115V, 10.4A, 1500W

Certifications

• AHRI Certified
• UL Listed – Self-contained liquid chiller
• Assembled in USA – Charlotte, North Carolina

Condition

• Year of Manufacture: 2012
• Used, professionally maintained
• Sold as-is

Applications

• Large commercial buildings
• Industrial cooling systems
• Hospitals and data centers
• Central chilled water plants
